Bent-glued parts
Glued furniture parts, bed slats
Glued furniture parts are divided into the following main groups: bow-shaped, L-shaped, P-shaped, angled glued furniture parts, glued furniture parts with line string form, glued furniture parts with spherical form and open contour, and flat-glued furniture parts.
Elastic effect of glued furniture parts is used in production of both cheap furniture meant for wide range of clients and elite one used in the most prestigious interiors.
Glued furniture parts (prodused by filial company- CJSC "Pinskdrev-Pinwood") are certified according to CARB regulations (California Air Resources Board) and IKEA specifications IOS-MAT-0003.
Version no.: AA-10899-8, 2008-10-14.
Main characteristics of glued furniture parts and bed slats (latoflex) (GOST21178-2006)
| Shape | Bow-shaped and angled |
| Curve radius | 3500, 4000-5000, 8000 mm |
| Dimension | Thickness - 8, 9, 10, 11, 12 mm Width - 25-100 mm Length - 500-990 mm (R=3500 mm) Length - 600-1500 mm (R=5000 mm) |
| Kind of treatment | Pitched |
| Raw material | Round broad-leaved timber (alder, birch) |
| Materials | Carbamide-formaldehyde resin KF-O acc. to GOST 14231-88, ammonium chloride ac. to GOST 2210-73 |
| Humidity | No more than 10% (8-10% by fact) |
| Limit of strength when splitting off statically | No less than 56 MPa (80-120 MPa by fact) |
1. Glued furniture parts for chairs:
| Name | Image | Production | Name | Image |
|---|---|---|---|---|
|
1.1Angled shape with one curve Dimension: 700x500x24 mm |
 |
 |
1.6 Angled shape with several curves Dimension: 860x500x25 mm |
 |
|
1.2 П-shaped Dimension: 1200x500x25 mm |
 |
1.7 П-shaped with several curves Dimension: 1600x400x30 mm |
 |
|
|
1.3 Bow-shaped with several curves Dimension: 820x550x10 mm |
 |
1.8 Bow-shape with several curves Dimension: 860x500x20 mm |
 |
|
|
1.4 Bow-shaped with one curve Dimension: 1100x450x26 mm |
 |
1.9 Bow-shape with one curve Dimension: 500x500x15-30 mm |
 |
|
|
1.5 Flat shape Dimension: 400-2100x650x10-30 mm |
 |
2. Seats and backs for ofice furniture:
| Name | Image | Production | Name | Image |
|---|---|---|---|---|
|
2.1 Back Dimension: 430x460x10 mm |
 |
 |
2.6 Seat Dimension: 438x465x7,5 mm |
 |
|
2.2 Back Dimension: 355x440x14 mm |
 |
2.7 Seat Dimension: 390x439x10 mm |
 |
|
|
2.3 Back Dimension: 370x465x8 mm |
 |
2.8 Seat Dimension: 400x390x10 mm |
 |
|
|
2.4 Back Dimension: 325x475x8 mm |
 |
2.9 Seat Dimension: 396x458x8 mm |
 |
|
|
2.5 Back Dimension: 750x495x13 mm |
 |
2.10 Seat Dimension: 432x450x7,5 mm |
 |
3. Seats and backs for school furniture:
| Name | Image | Production | Name | Image |
|---|---|---|---|---|
|
3.1 Back Dimension: Groups:1-2, 3-4, 5-6 Length:100,115,130 Width:302,342,382 Thickness: (8-10) mm |
 |
 |
3.4 Seat Dimension: Groups: 1-2, 3-4, 5-6 Length: 256,280,320 Width:302,342,382 Thickness: 8-10 mm |
 |
|
3.2 Back (open contour, bow-shape with one curve) Dimension: Groups: 3, 4, 5-6 Length:310,320,382 Width:160,180,200 Thickness: (8-10) mm |
 |
3.5 Seat (open contour, angled shape with spherical cavity in the center) Dimension: Length: 256,280,320 Width: 302,342,382 Thickness: 8-10 mm |
 |
|
|
3.3 Back (open contour,angled shape) Dimension: Groups: Length:115,130 Width: 350,390 Thickness: 10 мм |
 |
3.6 Seat (open contour, angled shape with bow-shaped cavity in the center) Dimension: Length: 330, 380 Width: 340, 380 Thickness: 10 mm |
 |
| 4. Bars and slats for bed frames | 5. Kinds of bed frames furniture | ||
|---|---|---|---|
|
Dimension: according to buyers order
|
Dimension: according to buyers order
|
||
| 4.1 Bars |
 |
Bed frame №1
 |
Bed frame №3
 |
| 4.2 Milled bars with additive |
 |
||
| 4.3 Pitched bed slats covered with film |
 |
Bed frame №2
 |
Bed frame №4
 |
Also our company produces Pallets |
|
Package and transportation of glued furniture parts
By agreement with customer glued furniture parts can be packed up in packages of other weight according to the contract. Each package is marked with the following information: 1) country of producer; 2) factory of producer and (or) his logo; 3) conventional designation of glued furniture parts; 4) quality of glued furniture parts in package; 5) designation of national confirmation sign for certified production. When exporting additional marking is allowed/ |
We would be glad to consider any of your business propositions.
